Description
High speed automatic pillow packing machine
This Packaging Machine is mainly used for various kinds of solid objects with regular shape,such as food(bread/cake/butter/cream/cheese/cookies/bars/pies), pharmaceuticals tools, daily necessities, hardware, or any other products loaded in box or tray.It can automatically complete bag making, measuring, filling, sealing, cutting, counting, and can configure printing batch numbers according to customer requirements.
Horizontal Pillow Bag Automatic Flow Packing Machine
Advanced electronic anti-cutting, electronic anti-empty bag algorithm. The empty material film stops, saving packaging materials.
The horizontal seal is controlled by an independent servo motor, and the longitudinal seal and the feeding tailstock are controlled by a frequency conversion motor. The mechanical structure is simple, the operation is stable, and the noise is low.
The feeding speed is automatically tracked, and the packaging machine automatically accelerates and decelerates. High speed,
higher precision, double knife speed can reach 300 packs/min, error ±1mm
The horizontal seal is controlled by an independent servo motor, and the longitudinal seal and the feeding tailstock are controlled by a frequency conversion motor. The mechanical structure is simple, the operation is stable, and the noise is low.
The feeding speed is automatically tracked, and the packaging machine automatically accelerates and decelerates. High speed,
higher precision, double knife speed can reach 300 packs/min, error ±1mm
*Optional configuration: coding machine, double support paper, automatic film connection, inflation, spray alcohol, lifting panel,stainless steel machine body.
Intelligent control panel
Human-machine interface parameter setting is convenient and fast Supports multiple languages and can be switched freely Fault self-diagnosis function, fault display is clear at a glance
Bag forming
Bag width can be adjusted easily,Wide adaptability range.
so customer just need to advise the min and the max sizes of your products, so we can recommend the suitable model.
so customer just need to advise the min and the max sizes of your products, so we can recommend the suitable model.
Film shelf
Up film:
Sealed at the bottom, suitable for pack-aging single items, with trays,items that need to distinguish between positive and negative.
Down film:
Sealing on the top, suitable for bulk,multiple items packaging.
Sealed at the bottom, suitable for pack-aging single items, with trays,items that need to distinguish between positive and negative.
Down film:
Sealing on the top, suitable for bulk,multiple items packaging.
High sensitive optical
Electric color code tracking system and digital input cutting position ensure accurate sealing, cutting, and coding positions
Date code printer
Ink wheel date printer is the standard of packaging machine,Text can be
customized according to customer needs.
customized according to customer needs.
High quality alloy cutting head
Quick sealing and cutting,
non stick bag, neat incision Positioning shutdown function, non stick knife, no waste of coating
Precision Circuit Design Concise and refined circuit layout to minimize faults
Electronic control module All controlled by software to run programming Realize reliable quality and easy maintenance
High quality appearance material Durable and stable, rust resistant and corrosion-resistant
Positioning universal wheel Convenient relocation and secure positioning
Product Features
1.Cross seal and middle seal are controlled by independent motor . With simple mechanical structure , stable operation and low noise.
2. High speed , high accuracy , the maximum speed can be up to 230 bags / min .
3. Human machine interface,convenient and smart parameter settings .
4. Automatic fault diagnosis function ,fault displayed clearly .
5. Color tracking , digital input seal cutting position , make the seal cutting position more accuracy .
6. Double supporting paper structure, automatic film connecting device , simple film changing , quick and accuracy .
7. All controls can be implemented by software system , facilitate functional tuning and technical upgrading , and never fall behind .
1.Cross seal and middle seal are controlled by independent motor . With simple mechanical structure , stable operation and low noise.
2. High speed , high accuracy , the maximum speed can be up to 230 bags / min .
3. Human machine interface,convenient and smart parameter settings .
4. Automatic fault diagnosis function ,fault displayed clearly .
5. Color tracking , digital input seal cutting position , make the seal cutting position more accuracy .
6. Double supporting paper structure, automatic film connecting device , simple film changing , quick and accuracy .
7. All controls can be implemented by software system , facilitate functional tuning and technical upgrading , and never fall behind .
Suitable for multiple packaging materials Polypropylene/polyethylene, aluminum foil/polyethylene, polyester/aluminum plated/polyethylene, nylon/reinforced polyethylene, paper/polyethylene, etc
